Yamato IC802 – 318 L Natural Convection Incubator up to 80°C
The Yamato IC802 is a large-capacity 318 L natural convection incubator featuring an air-jacket design for excellent temperature uniformity. It is suitable for sample incubation, culture applications and controlled-temperature testing in research, testing and quality-control laboratories.
Key Features
- Operating temperature range: ambient +5°C to 80°C.
- Chamber capacity: 318 L.
- Air-jacket and natural convection design for uniform temperature distribution.
- Temperature adjustment accuracy: ±0.5°C at 37°C.
- Temperature distribution accuracy: ±1.0°C at 37°C.
- Inner observation glass window helps minimize temperature changes when the outer door is opened.
- PID temperature control with timer, key-lock and self-diagnostic functions.
Typical Applications
- Controlled-temperature sample incubation.
- Microbial and biological culture.
- Biological, chemical and materials research.
- Testing and quality-control laboratories.
Key Specifications
| Model | IC802 |
| Type | Air Jacket, Natural Convection |
| Temperature range | Ambient +5°C to 80°C |
| Temperature adjustment accuracy | ±0.5°C at 37°C |
| Temperature distribution accuracy | ±1.0°C at 37°C |
| Chamber capacity | 318 L |
| Internal dimensions | 600 × 530 × 1000 mm |
| External dimensions | 710 × 656 × 1619 mm |
| Heater | 0.7 kW |
| Standard shelves | 4 |
| Power supply | AC220V, single phase |
| Weight | 102 kg |
Frequently Asked Questions
What type of incubator is the Yamato IC802?
The Yamato IC802 is an air-jacket natural convection incubator designed to provide stable and uniform temperature conditions in a 318 L chamber.
What is the maximum operating temperature of the Yamato IC802?
The Yamato IC802 operates from ambient temperature +5°C up to 80°C.
